2.3 Technical data of the individual components
2-34
Copyright © Siemens AG 2006
SINUMERIK 810D Equipment Manual Configuration CCU (PHC) – 03/2006 Edition
2.3 Technical data of the individual components
Table 2-10 General technical data
Security
Protection class I (protective conductor) as per EN 61800-5-1
Degree of protection
per EN 60529
IP20 or IPXXB
Approvals CE / cULus
Degree of contamination 2
Cooling Open circuit ventilation
Mechanical environmental conditions
Transport
(in transport packaging)
2M2 according to EN 60721-3-2
Storage 1M2 according to EN 60721-3-1
Table 2-11 Mechanical data
ÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁ
Component
ÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁ
Dimensions
width x height x depth in mm
ÁÁÁÁÁ
Á
ÁÁÁ
Á
ÁÁÁÁÁ
Weight
in kg
(approx.)
CCU box
3 axes
2 axes
ÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁ
150 x 490 x 268
Internal heat dissipation
Internal and external heat dissipation
ÁÁÁÁÁ
Á
ÁÁÁ
Á
ÁÁÁÁÁ
11.3
11.4
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
CCU
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
150 x 307 x 220
ÁÁÁÁÁ
ÁÁÁÁÁ
1.6
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
Single I/O module
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
50 x 374 x 153
ÁÁÁÁÁ
ÁÁÁÁÁ
1.7
ÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁ
NCU terminal block
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
257 x 100 x 40
ÁÁÁÁÁ
ÁÁÁÁÁ
0.5
Table 2-12 Electrical data
Components Rated voltage
Max. power loss at
rated voltage
Max. current
CCU box
3 axes
2 axes
Power supply via SIMODRIVE 611
power supply (I/R or OI module).
Power supply via other devices is not
permitted
Approx. 350 W
internal/external/total
69/ 111 /180 W
Refer to table 2-3
CCU
permitted.
Approx. 25 W Refer to table 2-3
Single I/O module 24 V for logic supply,
24 V for load supply,
0.3 A
12 A
NCU terminal block 24 V for logic supply, load supply directly
on the DMP module
0.5 A
2
Connection Conditions
