Siemens SINUMERIK 810M User Manual

4 Monitoring Functions 09.91
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text:
2076
”Incorrect G02/G03”
Reason:
Effect:
Remedy:
Direction of circle for the described contour is not possible
As for alarm 2072
As for alarm 2072
Alarm No.
Alarm Text:
2077
”Incorrect block sequence”
Reason:
Effect:
Remedy:
Several blocks are needed for the calculation of the contour path:
– Block sequence not correct
– Insufficient information (underdefined)
As for alarm 2072
As for alarm 2072
Alarm No.
Alarm Text:
2078
”Incorrect input parameter”
Reason:
Effect:
Remedy:
– Programmed parameter sequence not allowed
– Parameter sequence not complete for the described contour
As for alarm 2072
As for alarm 2072
Alarm No.
Alarm Text:
2081
”CRC not allowed”
Reason:
Remedy:
With selected TNRC/CRC (G41/G42), the following functions cannot
be programmed:
G33, G34, G35, G58, G59, G92, M19 S ...
First program cancellation of TNRC/CRC with G40 or D0
Alarm No.
Alarm Text:
2082
”CRC plane not determinable”
Reason:
Remedy:
The axes for the selected CRC/TNRC plane do not exist
Select correct plane with G16
Alarm No.
Alarm Text:
2087
”Coordinate rotation not permitted”
Remedy: Check NC program.
Alarm No.
Alarm Text
2088
”Battery alarm abs. submod. 1”
Reason:
Remedy:
Battery voltage is too low. Battery test is performed every 10 min.
Replace battery module on absolute encoder module 1 while the
control is switched on.
4-20
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02
SINUMERIK 810M, GA3 (BN)
