09.91 4 Monitoring Functions
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text
2089
”Battery alarm abs. submod. 2”
Reason:
Remedy:
Battery voltage is too low. Battery test is performed every 10 min.
Replace battery module on absolute encoder module 2 while the
control is switched on.
Alarm No.
Alarm Text:
2152
”Spindle speed too high”
Reason:
Remedy:
The actual spindle speed is higher than that set in machine data.
– Program a smaller S value
– G92 S ... with v-constant
– Search for a block number in the ”EDIT” mode
(”AUTOMATIC”mode)
– Check or inform Service
Alarm No.
Alarm Text:
2153
”Control loop spindle HW”
Reason:
Effect:
Remedy:
As for alarm 132*
– Inhibiting of NC START
– Operation is brought to a defined standstill
As for alarm 132*
Alarm No.
Alarm Text:
2154
”Spindle measuring system dirty”
Reason:
Effect:
Remedy:
On measuring systems with a contamination signal, the measuring
system has signalled a fault to the NC
Inhibiting of NC START
Check the measuring system
Alarm No.
Alarm Text:
2155
”Option M19 not available”
Reason:
Effect:
Remedy:
”M19 S ...” has been programmed, although this function is not
present
Inhibiting of NC START
– Correct program
– Retrofit option ”M19”
Alarm No.
Alarm Text:
2160
”Scale factor not allowed”
Remedy: Modify scale factor
Alarm No.
Alarm Text:
2161
”Scale change not allowed”
Remedy: Correct scale factor modification
Alarm No.
Alarm Text:
2171
”Approach not possible”
Remedy: Correct approach block
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02 4-21
SINUMERIK 810M, GA3 (BN)
