4 Monitoring Functions 01.93
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text:
2172
”Retract not possible”
Remedy: Correct retraction block
Alarm No.
Alarm Text:
2173
”Wrong approach/retract plane”
Remedy: Correct approach/retraction plane
Alarm No.
Alarm Text:
2183
"Axis is not a rotary axis"
Reason:
Effect:
Remedy:
The axis must be declared a rotary axis in MD 564*, bit 5.
NC Start and NC Ready 2 disabled.
Set MD 564, bit 5 = 1.
Alarm No.
Alarm Text:
2184
"M fnct. for C axis invalid"
Alarm No.
Alarm Text:
2189
”Transformation undefined”
Reason:
Remedy:
– Type of transformation not defined.
– Option bit for the transformation not set.
– Transformation axes defined multiply or incorrectly.
Press the “RESET” key.
Alarm No.
Alarm Text:
2190
”Transformation axes assigned””
Explanation: When transformation is selected, one of the real axes of the
transformation grouping is programmed in another channel (except
channel 1).
Alarm No.
Alarm Text:
2191
”Transformation in zero”
Reason:
Remedy:
A real axis (usually the X axis) is in the zero on selection of transform-
ation (G131).
Press the “RESET” key.
