01.93 4 Monitoring Functions
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text:
2192
”Axis doubling (duplication) active”
Reason:
Effect:
Remedy:
– PLC signals QB 81.2 or QB 81.3 have changed outside the “Reset
state”.
– Traverse key pressed in “JOG mode” in “AUTOMATIC active”
state, while PLC signal QB 81.2 or QB 81.3 was active and
MD 5019.0 set.
– While axis duplication is active, the axial PLC signals (servo enable,
feedrate enable, mirror, follow-up, axis disable) are not the same for
both axes.
– PLC signals QB 81.2 and QB 81.3 at ”Zero” while option bits is set.
NC START inihibited.
Set PLC signals correctly.
Alarm No.
Alarm Text:
2193
"No additional axes possible"
Reason:
Remedy:
Only appears when a block search with calculation is initiated in the
target block and MD "Additional axis after block search with
calculation" is set, if
1. additional axes are to be programmed in G36 blocks,
2. additional axes are to be programmed in G98 blocks which have
no axes.
For 1. Block search with calculation to program block without G36
function.
For 2. Block search with calculation to program block without G98
function.
Alarm No.
Alarm Text:
2194
"G36 position rotary axis missing"
Reason:
Remedy:
The alarm only appears with modulo programming. The alarm is
triggered when a G98 is to be generated for the rotary axis in a G36
block (not with MD 572*, bit 4):
1. when the rotary axis is programmed for the first time after RESET
or after a C axis switchover using an M function,
2. when the rotary axis is programmed for the first time as from the
target block of a block search with calculation.
For 1: First program the C axis once with G0 or G01
(e.g. G0 G91 C = 0 LF).
For 2: Choose a target block with no G36 and where the C axis is
programmed until the G36 block (additional axes in target
block is also sufficient).
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02 4-23
SINUMERIK 810M, GA3 (BN)
