NOTICE
Impermissible mounting positions can cause malfunctions
Observe the permissible mounting position: Deviating by up to 5º from the vertical.
Only the shown mounting position is permitted.
Mounting
4.2Mounting the TCU on the operator panel front with mounting bracket
TCU 30.3
Equipment Manual, 03/2023, A5E40874197B AD 29
