Siemens SINUMERIK 840D

Additional functions
13.2 Check scope of NC language present (STRINGIS)
Job planning
13-4 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
Scope of NC language
All available language commands and in particular all those not needed and active language
commands are still known for SINUMERIK powerline. The scope of language to be checked
for SINUMERIK solution line depends on the pre-configured machine data and either
includes all known / just the approved options or active functions in the current scope of
NC language.
Scope of NC language Scope of NC language includes:
G codes of all existing G code groups such as G0, G1, G2,
INVCW, POLY, ROT, KONT, SOFT, CUT2D, CDON, RMB, SPATH
DIN or NC addresses such as ADIS, RNDM, SPN, SR , MEAS
NC language functions such as predefined subprograms
TANG(Faxis1..n, Laxis1..n, coupling factor).
NC language procedures (pre-defined procedures with return
value) such as subprogram with parameter transfer GETMDACT.
NC language procedures (pre-defined procedures without return
value) such as deactivate single block suppression SBLOF.
NC key words such as ACN, ACP, AP, RP, DEFINE, SETMS
Machine data $MN general, $MA axial, $MC channel-specific as
well as all setting data $S... and options data $O... .
NC system variables $ in the parts program and synchronized
actions as well as NC computing parameters R.
Return values
Basic information
Coding:
The return value is coded. The basic information included is
sub-divided into y and existing detailed information into x.
Test result, whether the current configuration includes:
000 The NCK is not aware of the STRING name.
100
The STRING name is a language command but cannot be
programmed, i.e. this function is inactive.
2xx
The STRING name is a programmable language command , i.e. this
function is active.
y00 Assignment not possible
y01 to y11 Value ranges for existing detailed information known.
400 For NC addresses which do not have xx=01 or xx=10 and are not
G code G or computing parameter R, see comments (1).
Note
During a check with, STRINGIS should no other coding be found, then the corresponding
NC language command can be programmed and 2xx coding applies.
