Additional functions
13.2 Check scope of NC language present (STRINGIS)
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
13-5
2xx value ranges of the detailed information
Detailed Information
Significance of the test result:
200 Interpretation not possible
201 A DIN address or NC address is defined, i.e. whether names
have recognized the address letters from this, see
comments (1)
202 G codes from the existing groups of G code have been
recognized.
203 NC language functions with return value and parameter transfer
are present.
204 NC language functions with return value and parameter transfer
are present.
205 NC key words are present.
206 General, axial or channel-specific machine data ($M...),
setting data ($S...) or option data($O...) are present.
207 User variables, such as NC system variables beginning with
$... or computing parameters beginning with R are present.
208 The cycle names have been loaded in NCK and cycle programs are
also activated, see comment (2).
209 The defined name has been recognized and activated GUD
variable found by global user variables (GUD variables).
210 The macro names along with the names defined and macros
activated in the macro definition files have been found, see
comment (3).
211 Of local user variables (LUD variables) whose name is
contained in the current program.
Note
Comments on the individual return values
(1) Fixed, standardized addresses are recognized as DIN addresses. The following
definitions for geometry axes apply for NC addresses with adjustable identifiers:
A, B, C for specified round axes, E is reserved for extensions and
I, J, K, Q, U, V, W, X, Y, Z for specified linear axes.
The axle identifiers can be programmed with an address extension and can be written for the
test, e.g. 201 = STRINGIS("A1").
The following addresses cannot be written with an address extension for the test and always
deliver the fixed value of 400.
Example 400 = STRINGIS("D") or specification of an address expansion where
0 = STRINGIS("M02") results in 400 = STRINGIS("M").
(2) Cycle parameter names cannot be checked with STRINGIS.
(3) NC address letters G, H, L, M defined as macros are identified as macros.
