SIPART DR20 Project Planning Manual
9. Ordering Data
SIPART DR20 S Standard controller with S output,
2 analog inputs for current,
1 digital input, 1 digital output
Power supply 230 V AC
Power supply 115VAC
Power supply 24 V AC / DC
6DR2001-1(A)
6DR2001-2(A)
6DR2001-4(A)
SIPART DR20 K Standard controller with K output,
2 analog inputs for current,
1 digital input, 1 digital output
Power supply 230 V AC
Power supply 115 V AC
Power supply 24 V AC / DC
6DR2004-1(A)
6DR2004-2(A)
6DR2004-4(A)
Analog input module For current / voltage
For resistance transmitters
For Pt 100 resistance thermometers
For thermocouples / mV-signals
6DR2800-8J
6DR2800-8R
6DR2800-8P
6DR2800-8T
Relay output module For alarm signals 6DR2801-8A
Digital output module For alarm signals and manipulated
variable output of S controller
6DR2801-8B
Serial interface module For serial communication (RS 232) 6DR2803-8A
Mains plug for 115/230 V *) C73334-Z343-C3
Mains plug for 24 V *) C73334-Z343-C6
Terminal block 8-way for standard K controller *) W73078-B4-A908
Terminal block 1 a-way for standard S controller *) W73078-B4-A910
Terminal block 4-way for input modules *) W73078-B4-A904
Terminal block 4-way for thermocouple input module *) C73451-A3000-B17
Terminal block 5-way for alarm module *) W73078-B5-A905
Plug for ribbon cable (interface) C73451-A347-D36
Scale for SIPART DR20 (front side printed ~ 10%) C73451-A3000-C21
Blank scale for SIPART DR20 C73451-A3000-C22
*) Included in scope of deliveries
101
