Project Planning Manual SIPART DR20
Setting of SIPART -Controller No. / Tag-No. ……………………………………….
Configuring Parameterization
Strs Setting Parameter Dis-
play
Setting
1
Derivative-action gain Vv uu
2
Proportional gain Kp cp
3
Reset time Tn tn
4
Working point Y0 Y0
5
Derivative-action time Tv tu
6
Filter time constant for xd TF tF
7
Setpoint ramp Tw tS
8
Valve positioning time Ty
9
Period y+ T+ tY
10
Period y- T- t-
11
12
Start-of-scale value 0 % LA
13
Vertex 1/8 12.5 % L1
14
Vertex 2/8 25 % L2
15
37.5 % L3
Vertex 3/8
16
Vertex 4/8 50 %
L4
17
Vertex 5/8 62.5 % L5
18
Vertex 6/8 75 % L6
19
Vertex 7/8 87.5 % L7
20
Full-scale value 100 % LE
21
22
Setpoint limitation Start wva/wa SA
23
Setpoint limitation End wve/we SE
24
Safety setpoint ws SH
25
26
Alarm value, minimum A2 A2
27
Alarm value, maximum A1 A1
28
29
A A
Response threshold of xd
30
31
Manipulated variable
limitation start of y
ya YA
32
Manipulated variable
limitation end of y
ye YE
33
Safety manipulated
variable
ys YS
34
35
Constant 1 (zero) c1
36
Constant 2 (factor) c2
37
38
39
40
41
42
43
44
45
46
47
48
136
