Operation
105
SIPAR T PS2 Manual
A5E00074631--06
.
NOTE
If the control function to close tightly is activated, for parameter
“49. LIM” the monitoring of the control deviation in each overrun direc-
tion (YCDO: < 0 %, YCUP: > 100 %) is disabled. This function is par-
ticularly useful for valves with a soft seating. For long term monitoring
of the end-stop positions, we recommend activating the parameters
“52. ZERO” and “53. OPEN”.
Value for tight closing, bottom
and
Value for tight closing, top
.
NOTE
“40.YCDO” must always be set to less than “41.YCUP”. The tight
closing function has a fixed hysteresis of 1 %. “40.YCDO” and
“41.YCUP” relate to mechanical stops and are independent of the
settings of “7.SDIR” and “38.YDIR”.
Function digital input 1 (see figure 4-6, page 96)
and
Function digital input 2 (see figure 4-6)
The parameters “BIN1” and “BIN2” can be set individually depending
on the purpose. The direction of action can be adapted to an NCC or
an NOC.
S BIN1 or BIN2 = on or --on
Digital messages of the periphery (e.g. pressure or temperature
switches) can be read out via the HART interface or lead to re-
sponding of the fault message output by OR linking with other mes-
sages.
S BIN1 = bLoc1
The Configuration operating mode is locked to prevent it being ad-
justed (e.g. by a wire jumper between terminals 9 and 10).
S BIN1 = bLoc2
If digital input 1 has been activated, manual operation is also locked
in addition to the Configuration operating mode.
S BIN1 or BIN2 = uP or doWn (contact closes) or --uP or --doWn (con-
tact opens).
The actuator drives the linear actuator to the upper or lower stop
when the digital input is activated with continuous contact.
S BIN1 or BIN2 (contact closes) = StoP or --StoP (contact opens).
40.YCDO
41.YCUP
42.BIN1
43.BIN2
