Introduction
13
SIPAR T PS2 Manual
A5E00074631--06
1
2
3
4
1 Actuator
2 Positioner, single-acting in metal housing
3 Lantern
4 Manometer block, single-acting
5Valve
5
Figure 1-1 Positioner mounted on linear actuator (single-acting)
1
2
3
1 Positioner double-acting in plastic housing
2 Part-turn actuator
3 Manometer block, double-acting
Figure 1-2 Positioner mounted on part-turn actuator (double-acting)
