Preparing for Operation
68
SIPAR T PS2 Manual
A5E00074631--06
3.4.3 Connection in type o f protection “n” version
Standard controller
+
J
4to20mA
6DR5010-xGxxx
6DR5020-xGxxx
6DR5011-xGxxx
6
7
8
9
10
A
E
Hazardous area zone 2
Non-hazardous area
Positioner
Digital input 1
Figure 3-28 Two-wire connection, EEx n
+
4to20mA
6DR5210-xGxxx
6DR5220-xGxxx
6DR5211-xGxxx
2
3
4
5
6
7
8
9
10
A
E
J
HART Communicator
Hazardous area zone 2
Non-hazardous area
Positioner
Digital input 1
Figure 3-29 Two-wire connection, EEx n
