Preparing for Operation
49
SIPAR T PS2 Manual
A5E00074631--06
3.3.3 Mounting kit “linear actuator” 6DR4004-8V and 6DR4004-8L
The scope of delivery of the mounting kit “linear actuator IEC 534
(3 mm to 35 mm)” are contained (ser. no. see figure 3-7, page 51):
Ser. no. pieces Designation Note
1 1 NAMUR mounting kit bracket
IEC 534
Standardized connection for mounting console with
ledge, column or plane surface
2 1 Pick-up bracket Guides the roller with carrier pin and turns lever
arm
3 2 Clamping assembly Mounting of pick-up bracket on actuator spindle
4 1 Carrier pin Assembly with roll (5) on lever (6)
5 1 Roll Assembly with driver pin (4) on lever (6)
6 1 Lever NAMUR Forstrokerange3mmto35mm
For stroke ranges> 35 mm to 130 mm (special deli-
very), lever 6DR4004-8L is required additionally
7 2 U bolt Only for actuators with columns
8 4 Hexagon head screw M8 x 20 DIN 933-A2
9 2 Hexagon head screw M8 x 16 DIN 933-A2
10 6 Lock washer A8 -- DIN 127-A2
11 6 Flat washer B 8,4 -- DIN 125-A2
12 2 Flat washer B 6,4 -- DIN 125-A2
13 1 Spring VD--115E 0.70 x 11.3 x 32.7 x 3.5
14 1 Spring washer A6 -- DIN 137A-A2
15 1 Lock washer 3.2 -- DIN 6799-A2
16 3 Spring washer A6 -- DIN 127-A2
17 3 Socket cap screw M6 x 25 DIN 7984-A2
18 1 Hexagon nut M6 -- DIN 934-A4
19 1 Square nut M6 -- DIN 557-A4
21 4 Hexagon nut M8 -- DIN 934-A4
Table 3-1 Scope of delivery of the mounting kit “linear actuator”
