Operation
122
SIPAR T PS2 Manual
A5E00074631--06
4.5 Diagnosis
4.5.1 Diagnostic display
To access the diagnostic display in automatic or manual mode,
press all three buttons for at least two seconds.
This following table gives an overview of the values that can be
displayed. The third column contains the term from which the
abbreviation is derived, unless it is self-explaining.
The structure of the diagnostic display is similar to that in “Configu-
ration” mode: the upper line shows the diagnosis value, the lower line
shows the number and abbreviation of the displayed value.
Use the operating mode button
to select the next diagnosis value.
By pressing and holding the operating mode button and simultaneously
pressing the decrement button
the diagnosis values can be
selected in reverse order.
Certain values can be set to zero by pressing the increment button
for at least 5 seconds. This is noted in the last table column.
Some diagnosis values can be greater than 99999. In this case, the
display switches to exponential indication. Example: the value for
1234567 is displayed as 1.23E6.
No. Abbre-
viation
Meaning Values than
can be
indicated
Unit Reset
possible
1 STRKS Number of strokes (Strokes) 0to4.29E9 -- x
2 CHDIR Changes of direction (Changes of Direction) 0to4.29E9 -- x
3
CNT
Number of fault messages ( Counter) 0to4.29E9 -- x
4 A1CNT Number of alarms 1 (Alarm 1Counter) 0to4.29E9 -- x
5 A2CNT Number of alarms 2 (Alarm 2Counter) 0to4.29E9 -- x
6 HOURS Operating hours (Hours) 0to4.29E9 hours
7 WAY Determined actuator travel (Way) 0to130 mm or _
8 TUP Actuating time up (Travel Time Up) 0 to 1000 s
9 TDOWN Actuating time down (Travel Time Down) 0 to 1000 s
10 LEAK Leakage (Leakage) P 0.0 to 100.0 %
11 PST
Monitoring of the Partial Stroke Test
OFF / ###.#,
fdini, notSt,
SdtSt, fdtSt,
notd, Strt
s for ###.#
12 PRPST Time since the last Partial Stroke Test ###, notSt,
Sdtst, fdtSt
days
13 NXPST Time until the next Partial Stroke Test ###, notSt,
SdtSt, fdtSt
days
14 DEVI General control valve malfunction Off, 0.0 to
100.0
%
15 ONLK Pneumatic leakage Off, 0.0 to
100.0
--
16 STIC Slipstick effect Off, --100.0 to
100.0
%
17 ZERO Zero point offset Off, --100.0 to
100.0
%
18 OPEN Shifting the upper stop Off, --100.0 to
100.0
%
19 PAVG Average position value 0.0 to 100.0 %
20 P0 Potentiometer value lower stop (0%) 0.0 to 100.0 %
