Operation
123
SIPAR T PS2 Manual
A5E00074631--06
No. Reset
possible
UnitValues than
can be
indicated
MeaningAbbre-
viation
21 P100 Potentiometer value upper stop (100%) 0.0 to 100.0 %
22 IMPUP Pulse length up (Impulse Length Up) 2to160 ms
23 IMPDN Pulse length down (Impulse Length Down) 2to160 ms
24 DBUP Dead zone up (Dead Band Up) 0.1 to 10.0 %
25 DBDN Dead zone down (Dead Band Down) 0.1 to 10.0 %
26 SSUP Short step zone up (Short Step Zone Up) 0.1 to 100.0 %
27 SSDN Short step zone down (Short Step Zone Down) 0.1 to 100.0 %
28 TEMP Current temperature --40 to 85 _C
29 TMIN Minimumtemperature (“min/max pointer”) --40 to 85 _C
30 TMAX Maximumtemperature (“min/max pointer”) --40 to 85 _C
31 T1 Number of operating hours in temperature range 1 0to4.29E9 hours
32 T2 Number of operating hours in temperature range 2 0to4.29E9 hours
33 T3 Number of operating hours in temperature range 3 0to4.29E9 hours
34 T4 Number of operating hours in temperature range 4 0to4.29E9 hours
35 T5 Number of operating hours in temperature range 5 0to4.29E9 hours
36 T6 Number of operating hours in temperature range 6 0to4.29E9 hours
37 T7 Number of operating hours in temperature range 7 0to4.29E9 hours
38 T8 Number of operating hours in temperature range 8 0to4.29E9 hours
39 T9 Number of operating hours in temperature range 9 0to4.29E9 hours
40 VENT1 Number of switching operations pilotvallve 1 0to4.29E9 --
41 VENT2 Number of switching operations pilotvallve 2 0to4.29E9 --
42 STORE Save current values as “last maintenance”
(press increment button for 5s) (Store)
-- --
43 PRUP Prediction up 1to40 --
44 PRDN Prediction down 1to40 --
45 WT00 Number of operating hours in actuating range WT00 0to4.29E9 hours x
46 WT05 Number of operating hours in actuating range WT05 0to4.29E9 hours x
47 WT10 Number of operating hours in actuating range WT10 0to4.29E9 hours x
48 WT30 Number of operating hours in actuating range WT30 0to4.29E9 hours x
49 WT50 Number of operating hours in actuating range WT50 0to4.29E9 hours x
50 WT70 Number of operating hours in actuating range WT70 0to4.29E9 hours x
51 WT90 Number of operating hours in actuating range WT90 0to4.29E9 hours x
52 WT95 Number of operating hours in actuating range WT95 0to4.29E9 hours x
53 mA Setpoint current 0.0 to 20.0 mA
Table 4-1 Overview of diagnosis values
4.5.2 Meaning of the diagnosis values
Number of strokes
During operation, the actuator movements are added up and can be
read off here as the number of strokes. Unit: 100% strokes, i.e. the
path between 0 and 100 % and back. The value is written into a
non-volatile memory every 15 minutes. It can be set to zero with the
increment button
.
Number of changes of direction
1 STRKS
2 CHDIR
