Siemens SIPART PS2 6DR50xx User Manual

Introduction
14
SIPAR T PS2 Manual
A5E00074631--06
1
2
3
4
1 Actuator
2 Positioner, single-acting in explosion proof housing
3 Lantern
4 Manometer block, single-acting
Figure 1-3 Explosion proof version of the positioner mounted on linear actuator (single-acting)
1
2
3
1 Positioner double-acting in explosion proof housing
2 Part-turn actuator
3 Manometer block, double-acting
Figure 1-4 Explosion proof version of the positioner mounted on part-turn actuator (double-acting)
Table 1-1

Siemens SIPART PS2 6DR50xx Specifications

General

Brand	Siemens
Model	SIPART PS2 6DR50xx
Category	Valve Positioners
Language	English
