Operation
140
SIPAR T PS2 Manual
A5E00074631--06
Messages during the installation phase:
Upper line Lower line
Meaning/cause Measure
P---- x See above See above
RUN 1 x Initialization has been started, part 1
is active
(direction of action is being
determined)
S Wait
RUN 2 x Initialization, part 2 is active
(actuator travel check and
determination of the end stops)
S Wait
RUN 3 x Initialization, part 3 is active
(determination and display of the
actuating times)
S Wait
RUN 4 x Initialization, part 4 is active
(determination of the minimum
actuator increment length)
S Wait
RUN 5 x Initialization, part 5 is active
(optimization of the transient
response)
S Wait until “FINSH” is displayed
(initialization completed successfully)
S Press the operating mode button
briefly to acknowledge and exit the
configuration level by pressing it
continuously
YEND1 x only for manual initialization
first end position can be approached
S Approach first end position with the
“+”or“--”button
S Press operating mode button to
acknowledge
YEND2 only for manual initialization
second end position can be
approached
S Approach second end position with
the “+” or “--” button
S Press operating mode button to
acknowledge
RANGE x only for manual initialization
End position or measuring span are
outside the permitted measuring
range
S Press the “+” and “--” buttons to
approach another end position and
acknowledge with the operating
mode button,
or
S adjust the friction clutch until “ok”is
displayed and acknowledge with the
operating mode button
or
S cancel the initialization by pressing
the operating mode button, switch to
P manual mode and correct the
actuator travel and the position
displacement sensor
ok only for manual initialization
permitted measuring range of the
end positions has been reached
S Acknowledge with the operating
mode button, the remaining steps
(“RUN1”to“FINSH”) run
automatically
RUN 1/
ERROR
x Error in RUN 1
no movement e.g. due to insufficient
compressed air
S Make sure there is sufficient
compressed air
S Open reactor(s)
S Restart initialization
d___U x Bar graph display of the zero point
Zero point is outside the tolerance
range
S Usefrictionclutchtosetbetween
“P4.0” and “P9.9”(>0<)
S Continue with the “+” or “--” button
SEt
MIDDL
x
x
Friction clutch has been misadjusted;
no “P 50.0” display if the lever is in
horizontal position
S With linear actuators, press the “+”
and ”--” buttons to move the lever at
right angles to the s pindle
S Press operating mode button briefly
to acknowledge (initialization is
continued)
