Operation
142
SIPAR T PS2 Manual
A5E00074631--06
Messages on exiting configuration mode:
Upper
line
Lower
line
Auto-
matic
Manua
l mode
P manual
mode
Meaning/cause Measure
4.nn.nn
VER
x
x
Software version S Wait
Error
SLnn
x
x
Monotony violation of the
free characteristic curve at
vertice n
S Correct value
Messages during operation:
Upper
line
Lower
line
Auto-
matic
Manua
l mode
P manual
mode
Meaning/cause Measure
CPU
START
x
x
Message after applying the
electrical power supply
S Wait
HW /
ERROR
x Hardware error S Replace electronics
NOINI x x Positioner is not initialized S Start initialization
nnn.n x x x Actual position [in %] with
initialized positioner. Flashing
decimal point indicates com-
munication with a class 2
master
AUTnn x x Automatic mode
(nn = setpoint)
MANnn x Manual mode (nn = setpoint) S Press operating mode
buttontoswitchto
automatic mode
oFL / 127.9 x x x Display range was exceeded.
Possible causes:
S friction clutch or
S transmission ratio selector
were misadjusted or
S positioner was fitted on
another actuator without
re-initialization.
S Adjust friction clutch in
such a way that the
indication of the actual
value remains between
0.0 and 100.0 on
moving the actuator or
S switch over the
transmission ratio
selector or
S set to the factory s etting
(preset) and initialize
EXSTP x x Actuator was stopped via
binary input
EX UP x x Actuator is moved to the
upper stop via binary input
EXDWN x x Actuator is moved to the
lower stop via binary input
EXTPSt Partial stroke test was
activated e.g. via binary input
InPSt cyclic partial stroke test
HTCNF x x x x HARD configuration running
