Siemens SIPART PS2 6DR50xx User Manual

Preparing for Operation
56
SIPAR T PS2 Manual
A5E00074631--06
positioner
part-turn actuator
3 16, 17 10 4.1 9
A
25
2
14, 15
15
B
CUT A -- B
4.2 14, 15
G1/4
2 Coupling wheel 10 Feedback shaft
3 Carrier 14 Hexagon head screw M6 x 12
4 Multiple plate 15 Lock washer S6
4.1 Scale 16 Fillister head screw M6 x 12
4.2 Pointer mark 17 W asher
9 VDI/VDE 3845-mounting bracket 18 Hexagon socket head screw
Figure 3-10 Mounted positioner for part-turn actuator
