Siemens SIPART PS2 6DR50xx User Manual

Preparing for Operation
60
SIPAR T PS2 Manual
A5E00074631--06
+
4to20mA
6DR53x0-xNxxx
6DR52x5-xExxx
6DR53x5-xExxx
Positioner
2
3
4
5
6
7
8
9
10
A
E
J
HART Communicator
Only for:
6DR52x5-xExxx
Digital input 1
Figure 3-14 Two-wire connection
+
0/4to20mA
6DR53x0-Nxxx
6DR52x5-Exxx
6DR53x5-Exxx
Positioner
2
3
4
5
Digital input 1
6
7
8
9
10
A
E
*)
*) only for three-wire connection
+
18 to 30 V
U
*)
HART Communicator
Only for:
6DR52x5-xExxx
J
Figure 3-15 Three-/four-wire connection
