Siemens SIPART PS2 6DR50xx User Manual

Preparing for Operation
66
SIPAR T PS2 Manual
A5E00074631--06
U
H
61
62
61
62
J
E
I
y
module
6DR4004-6J
+
+
J
EEx
U
+
≤30 V
Non-hazardous area
Intrinsically safe power source
Hazardous area zone 1 or zone 2
Figure 3-24 I
y
-module 6DR4004-6J, EEx i
Digital inputs and outputs
Alarm module
6DR4004-6A
+
11
12
≥1
21
22
+
31
32
41
42
51
52
EEx
EEx
EEx
EEx
+
+
+
2K1
2K1
2K1
10K
10K
10K
3V
8.2 V
8.2 V
8.2 V
≤25.2 V
Hazardous area zone 1 or zone 2
Non-hazardous area
Digital
input 2
Fault
message
Limit value A1
Limit value A2
Intrinsically safe
switching
amplifier to DIN
EN 60947-5-6
Figure 3-25 Alarm module 6DR4004-6A, EEx i
Current output
