Siemens SIPROTEC 7SD610 User Manual

Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
371
1)
Not possible with surface mounting housing (position 9 = F). For the surface mounting version, please order a device
with the appropriate electrical RS485 interface and accessories as stated in Appendix A.1.2 „External converters“.
2)
Not possible with surface mounting housing (position 9 = F).
1)
For surface-mounting housing (MLFB position 9 = F), delivery with external repeater
2)
This interface is only available in the flush-mounting housing (MLFB position 9 # F).
Additional Specification
L for Further System Interfaces (Port B)
(only if Pos. 11 = 9)
Pos. 21 Pos. 22
Profibus DP Slave, electrical RS485 0 A
Profibus DP Slave, optical, 820 nm, double ring, ST connector
1)
0B
MODBUS, electrical RS 485 0 D
MODBUS, 820 nm, optical, ST connector
1)
0E
DNP 3.0, electrical RS485 0G
DNP 3.0, optical, 820 nm, double ring, ST connector
1)
0H
IEC 61850, 100 Mbit Ethernet, double electrical, RJ45 connector 0 R
IEC 61850, 100 MBit Ethernet, optical, double, Duplex LC connector
2)
0S
Function Interface (Port C and D) Pos. 12
see Additional Specification M 9
Additional Specification
M for DIGSI/modem interface and protection data interface 1
(device rear, port C and D)
Pos. 23 Pos. 24
Port C: DIGSI/Modem/Browser, electrical RS232 1
Port C: DIGSI/Modem/Browser, electrical RS485 2
Port D: FO5 optical, 820 nm, 2 ST connectors, length of optical fibre up to 1.5 km,
for FO direct connection or communication networks using multimode fibre
A
Port D: FO6 optical, 820 nm, 2 ST connectors, length of optical fibre up to 3.5 km,
for FO direct connection using multimode fibre
B
Port D: FO17 optical, 1300 nm, 2 LC duplex connectors, length of optical fibre up to 24 km,
for FO direct connection using monomode fibre
1)
G
Port D: FO18 optical, 1300 nm, 2 LC duplex connectors, length of optical fibre up to 60 km,
for FO direct connection using monomode fibre
1)
H
Port D: FO19 optical, 1550 nm, 2 LC duplex connectors, length of optical fibre up to 100 km,
for FO direct connection using monomode fibre
1)
J
Port D: FO30 optical, 820 nm, 2 ST connectors, length of optical fibre up to 1.5 km,
for FO direct connection or communication networks with IEEE C37.94 via multimode fibre
2)
S
Functions 1 Pos. 13
Three-pole tripping, without automatic reclosure 0
Three-pole tripping, with automatic reclosure 1
1-/3-pole tripping without automatic reclosure 2
1-/3-pole tripping with automatic reclosure 3
