Installing the vibration and shock kit for direct-on-line starters in sizes S00 and S0
The following 󹪝gures show how to install the vibration and shock kit 8US1998‑1CA10.






0.5 mm - 1 mm
0.4 Nm
Figure 7-49 Installing the vibration and shock kit, direct-on-line starter, screw-type connection system,
size S00
Installing the vibration and shock kit for direct-on-line starters in size S2
The following 󹪝gures show how to install the vibration and shock kit for direct-on-line starters
in size S2.
Mounting
7.3 Assembly and disassembly with di󹪜erent mounting systems
