10.5 Accessories for busbar mounting
The following kits for reversing operation are available for busbar mounting in various
connection systems and sizes.
Table 10-5 Assembly kit for reversing operation for busbar (size S00)
Screw connection Spring-loaded connection system
3RA2913‑1DB1 3RA2923‑1EB1 3RA2913‑1DB2
--- Auxiliary wiring module
(top and bottom)
Auxiliary wiring module (top)
Wiring modules (top and bottom) Wiring modules (top and bottom)
Connection clips (2 x) Connection clips (2 x)
Mechanical interlock Mechanical interlock
Busbar adapter Busbar adapter
Device holder Device holder
Table 10-6 Assembly kit for reversing operation for busbar (size S0)
Screw connection Spring-loaded connection system
3RA2923‑1DB1 3RA2923‑1DB2
Wiring modules (top and bottom) Wiring modules (top and bottom)
Auxiliary wiring module (top and bottom) Auxiliary wiring stranded wires
Connection clips (2 x) Connection clips (2 x)
Mechanical interlock Mechanical interlock
Busbar adapter Busbar adapter
Device holder Device holder
Spacer (2 x)
Table 10-7 Assembly kit for reversing operation for busbar (size S2)
Screw connection
3RA2933-1DB1
Busbar adapters and device holders Connector for contactors (2x)
Wiring modules (top and bottom) Mechanical interlock
Auxiliary wiring module (top and bottom) Screw and plain washer for mounting devices (2x)
Accessories
10.5 Accessories for busbar mounting
SIRIUS 3RA Load Feeders
Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004 129
