Screw connection Spring-loaded connection system
3RA2923‑1BB1 3RA2923‑1BB2
Screw (2 x) Screw (2 x)
Screw (2 x) for AC feeders
Spacer (2 x)
Table 10-3 Assembly kit for reversing operation for DIN rail (size S2)
Screw connection
3RA2933‑1BB1
DIN rail adapter (2 x) Mechanical interlock
Wiring modules (top and bottom) Connector for contactors (2 x)
Auxiliary wiring module (top and bottom) Screw and plain washer for mounting devices (3 x)
Side module (2 x) Operating instructions
Link wedge (4 x)
Table 10-4 Assembly kit for reversing operation for DIN rail (size S3)
Screw connection
3RA2943‑1BB1
DIN rail adapter (2 x) Mechanical interlock
Wiring modules (top and bottom) Connector for contactors (2 x)
Auxiliary wiring module (top and bottom) Screw and plain washer for mounting devices (6 x)
Side module (3 x) Operating instructions
Link wedge (6 x)
Reference
More information ... Can be found in the chapter titled ...
About mounting the assembly kit for the DIN rail On DIN rail with DIN rail adapter (Page 64).
Accessories
10.4 Accessories for DIN rail mounting
SIRIUS 3RA Load Feeders
128 Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004
