①/
②
Press the locking devices down with a screwdriver. Then push the DIN rail adapter with mounted
feeder forwards against the pressure of the mounting spring.
③ Pull the DIN rail adapter with mounted feeder forwards with a swivel action.
④ Press the DIN rail adapter with mounted feeder upwards and remove the DIN rail adapter with
mounted feeder from the DIN rail.
7.3.2.3 Mounting direct-on-line starters and reversing starters on DIN rail adapters (size S3)
Mounting the DIN rail adapter on the DIN rail
The DIN rail adapter snaps onto the DIN rail (no tools are required).
