Dimension drawings (dimensions in mm)
C
C.1 CAx data
You can 󹪝nd the CAx data in the Siemens Industry Online Support (
https://
support.industry.siemens.com/cs/ww/en/ps/16288/td).
1. Enter the full article number of the desired device in the "Product" 󹪝eld, and con󹪝rm with the
Enter key.
2. Click the "CAx data link.
Note
All dimensions are speci󹪝ed in mm.
