Siemens SIRIUS 3RA

C.2 3RA2 fuseless load feeders – Size S00 to S3 for DIN rail
3RA2 fuseless load feeders – Size S00 for DIN rail






Figure C-1 S00 direct-on-line starter, AC/DC, screw-type connection system3RA2110-..A






Figure C-2 S00 direct-on-line starter, AC/DC, spring-loaded connection system3RA2110-..E
Dimension drawings (dimensions in mm)
C.2 3RA2 fuseless load feeders – Size S00 to S3 for DIN rail
SIRIUS 3RA Load Feeders
140 Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004
