Figure C-3 S00 direct-on-line starter, AC/DC, hybrid connection system, link module 3RA2911‑2FA00
Note
The version of the fuseless load feeder (S00 direct-on-line starter, AC/DC) with hybrid connection
system is not available as a 3RA2 pre-assembled combination.
Figure C-4 S00 reversing starter, AC/DC, screw-type connection system3RA2210-..A
Dimension drawings (dimensions in mm)
C.2 3RA2 fuseless load feeders – Size S00 to S3 for DIN rail
SIRIUS 3RA Load Feeders
Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004 141
