Figure C-18 Direct-on-line starter S2 with 3RW4.3 soft starter, screw-type connection system, DIN-rail
adapter 3RA2932‑1CA00
Dimension drawings (dimensions in mm)
C.2 3RA2 fuseless load feeders – Size S00 to S3 for DIN rail
SIRIUS 3RA Load Feeders
Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004 149
