Siemens SIRIUS 3RA

3RA2 fuseless load feeders – Size S2 for 60 mm busbar systems







Figure C-38 Direct-on-line starter S2, screw-type connection system3RA2130‑4.A..-...., busbar
adapter 8US1261‑6MT10
Dimension drawings (dimensions in mm)
C.3 3RA2 fuseless load feeders – Size S00 to S2 for 60 mm busbar systems
SIRIUS 3RA Load Feeders
Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004 163
