④ Take the link module o the contactor.
Figure 7-16 Disassembling an S0 load feeder with spring-loaded connection system
Note
Proceed in the same way to disassemble the reversing starter (size S0).
Mounting
7.2 Mounting and disassembling load feeders
SIRIUS 3RA Load Feeders
56 Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004
