No tools are required for mounting and disassembling sizes S00 and S0. A screwdriver is required
for mounting and disassembling size S2.
Note
Vibration or shock load on size S00 reversing starters
In the case of vibration or shock load (such as in railway applications, for example), the fuseless
load feeder (size S00 reversing starter) has to be mounted on a DIN rail adapter to protect the
individual devices against damage.
Figure 7-23 Mounting on DIN rail without adapter (size S00)
Mounting
7.3 Assembly and disassembly with dierent mounting systems
SIRIUS 3RA Load Feeders
Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004 63
