Figure 7-29 Connection of DIN-rail adapters (size S00 and S0)
Figure 7-30 Connection of DIN-rail adapters (size S2)
Figure 7-31 Connection of DIN-rail adapters (size S3)
Mounting
7.3 Assembly and disassembly with dierent mounting systems
SIRIUS 3RA Load Feeders
Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004 69
