Technical data
B
B.1 General technical system data
General data
Line voltages and power ranges 3 AC 380 V ... 480 V, ±10 % (-15 % < 1 min), 4.8 kW ... 800 kW
1)
3 AC 500 V ... 690 V, ±10 % (-15 % < 1 min), 55 kW ... 1200 kW
1)
Line system configurations Line supplies grounded at the neutral point (TN/TT supply systems) or non-grounded line
supplies (IT supply systems)
Line frequency 47 ... 63 Hz
Output frequency Vector control: 0 ... 600 Hz
Servo control: 0 ... 650 Hz
U/f control: 0 ... 650 Hz
Line power factor fundamental
factor
Basic Line Modules:
> 0,96
Smart Line Modules:
> 0,96
Active Line Modules:
Adjustable (set in the facto‐
ry to cos φ = 1)
Efficiency > 99,0 % > 98,5 % > 97,5 %
Control method Servo control, vector control with and without sensor or U/f control
Fixed speeds 15 fixed speeds plus 1 minimum speed, can be parameterized
Speed ranges that can be skipped 4, parameterizable
Braking operation With regenerative feedback or by additional Braking Modules and braking resistors
Degree of protection IP20, IP21, IP23, IP43 and IP54
(with side panel, right or left)
Protection class Protection class I acc. to EN 61800-5-1
Overvoltage category III according to EN 61800-5-1
Limiting overvoltages
For
line supplies with a grounded line conductor and a line voltage > 600 VAC, line-side
components must be installed to limit overvoltages to overvoltage category II according
to EN 61800‑5‑1.
Degree of pollution 2 according to EN 61800-5-1
Cooling type Forced air cooling AF + WE + AN according to EN 6014
Touch protection BGV A 3 acc. to EN 50274
Cabinet system Rittal TS 8, doors with double-bit key, tripartite base plates for cable inlet
Paint finish RAL 7035 (indoor requirements)
Weight The relevant weight of a cabinet unit is specified on the test certificate supplied and on
the rating plate. The specified weight corresponds to the actual expansion stage of the
cabinet unit
1)
Power data for the basic version, power rating can be increased using a parallel connection.
Applications for Cabinet Modules, liquid cooled
Operating Instructions, 04/2015, A5E35974555A 141
