3.3.7 Disassembling the crane transport assembly
The cabinet are equipped either with transport eyebolts of lifting rails. Unscrew the crane
eyebolts or remove the lifting rails.
1.
Depending on the length of the cabinet or the transport unit, the lifting rails are attached
with a different number of screws. Release the screws to remove the lifting rails.
WARNING
Lifting rails can fall down
The lifting rails are heavy. If the lifting rails fall down, they can cause injury or material
damage.
Very carefully remove the lifting rails from the cabinet.
NOTICE
Screws in the converter
Screws can fall into the unit as it is disassembled and cause serious damage when the
equipment is started up.
After
removing the lifting rails, check as to whether all of the screws are available. Remove
any screws that have fallen into the converter.
Figure 3-7 Lifting rails
2. After
removing the transport eyebolts or the screws from the lifting rails, replace them with
the screws from the accessories pack. Only use the screws provided in order to maintain
the degree of protection and to ensure that the cabinet is correctly grounded.
Figure 3-8 Fixing screws
Preparations for use
3.3 Transport
Applications for Cabinet Modules, liquid cooled
Operating Instructions, 04/2015, A5E35974555A 55
