6. Use cable ties to secure the cable at appropriate locations.
7.
Connect the cable to the Control Unit.
Information regarding connecting the cable is provided in the "Control cabinets and
supplementary system components" manual.
5.4.4.2 Cable routing for DRIVE-CLiQ connections and signal cables
1. Route the DRIVE-CLiQ/signal cable from the bottom left in the cabinet.
2. Use cable ties to secure the cable at appropriate locations.
3. Feed the cable up through the cabinet and, at the height of the Control Unit, route it directly
up and to the right towards the Control Unit. Route the cable corresponding to the standard
cable prerouted in the cabinet.
4. Use cable ties to secure the cable at appropriate locations.
5. Connect the DRIVE-CLiQ/signal cable to the Control Unit.
5.4.4.3 Cable routing to the customer terminal block -X55
1. Route the cable for the customer terminal block from the bottom left in the cabinet.
2. Remove approximately 3 cm cable insulation from the cable at the height of the shield plate
in the lower section of the cabinet. Attach the cable to the shield plate.
3. Attach the cable by snapping the retaining clamp into the shield plate in an EMC-compliant
fashion.
4. Use cable ties to secure the cable at appropriate locations.
5. Guide the cable further up into the cabinet and, when it reaches customer terminal block -
X55, guide it to the left or right to -X55. Route the cable corresponding to the standard cable
prerouted in the cabinet.
6. Use cable ties to secure the cable at appropriate locations.
7. Connect the cables to the customer terminal block ‑X55.
Note
Optional interface -X55
You can find notes regarding the optional X-55 interface in the "SINAMICS S120 Cabinet
Modules" Manual, in Chapter "Interface description"
5.4.4.4 Cable routing for the Terminal Module TM54F
The cable routing corresponds to the cable routing to the customer terminal block -X55.
Connect the cables to the terminals to control the functions.
Electrical connection
5.4 Cable routing
Applications for Cabinet Modules, liquid cooled
90 Operating Instructions, 04/2015, A5E35974555A
