5.4.4.5 Cable routing for signal cables to SMC10/20/30 Sensor Module
1.
Route the cable for the customer terminal block from the bottom left in the cabinet.
2. Remove approximately 3 cm cable insulation from the cable at the height of the shield plate
in the lower section of the cabinet. Attach the cable to the shield plate.
3. Attach the cable by snapping the retaining clamp into the shield plate in an EMC-compliant
fashion.
4. Use cable ties to secure the cable at appropriate locations.
5. Guide the cable further up into the cabinet and, when it reaches the SMC10/20/30 Sensor
Module (‑B81/‑B82/‑B83), guide it to the right to the Sensor Module (encoder module).
Route the cable corresponding to the standard cable prerouted in the cabinet.
6. Use cable ties to secure the cable at appropriate locations.
7. Connect the cables to the SMC10/20/30 Sensor Module (‑B81/‑B82/‑B83).
5.4.4.6 Cable routing to connect the motor
1. Route the cable into the cabinet from below.
2. Feed the cable up through the cabinet to the motor connections –U2/-T1, -V2/-T2, -W2/-T3.
3. Connect the cable to the motor connections.
5.4.5 Cable routing for Active Line Modules
5.4.5.1 Checklist
Comply with the basic rules for cable routing (Page 86) when carrying out all cable routing and
connection work.
Route the following cables or carry out the following connection work:
Table 5-6 Checklist for cable routing and connection work
Cable routing Completed?
PROFIBUS cable or PROFINET cable to the Control Unit
DRIVE-CLiQ connections / signal cables to the Control Unit
Signal cables to the customer terminal block –X55
5.4.5.2 Cable routing for PROFIBUS or PROFINET connections to the Control Unit
1.
Route the cable for the Control Unit from the bottom left in the cabinet.
2. Remove approximately 3 cm cable insulation from the cable at the height of the shield plate
in the lower section of the cabinet. Attach the cable to the shield plate.
3. Attach the cable by snapping the retaining clamp into the shield plate in an EMC-compliant
fashion.
Electrical connection
5.4 Cable routing
Applications for Cabinet Modules, liquid cooled
Operating Instructions, 04/2015, A5E35974555A 91
Siemens Drives & PLCs
