Item Activity Applicable?/Completed?
9 Attach the separately supplied options for transport. This applies to the following options:
●
IP21 degree of protection with drip plate
● IP23/IP43/IP54 degrees of protection with canopy or filter elements
(Chapter "Description/description of the options").
10 If it is possible to enter the area underneath the cabinet units, it is essential that plant-
side shock protection is provided for this area.
11 Attach the handrail for the DC coupling including precharging circuit option.
(Chapter "Description/description of the options").
12 Before commissioning, install all of the shock protection measures, for example covers,
panels in and at the cabinet units.
14 The clearance around an open control cabinet door (evacuation route) specified in the
applicable accident prevention guidelines must be observed.
C.2 Electrical installation: Checklist
The checklist below guides you when electrically installing the cabinet. Read all the safety
information in the section "Safety information" before carrying out any work on the unit.
For
wiring instructions, see the "Electrical connection" section or refer to the documents listed
in the table below.
Note
Checking the checklist
If
the option in question is part of the delivery, check this accordingly in the right-hand column.
In the same way, check the boxes once you have finished the installation procedure to confirm
that the activities have been completed.
Table C-2 Electrical installation: Checklist
Activity Available/performed?
General information
The cables must be clamped to the cable strain relief rail (C rail).
The motor terminal box is equipped with the appropriate glands. These glands establish
contact
to the shield through a large surface area. When using EMC-shielded cables, the
glands connect the shield to ground. In the cabinet, the cable shields must be secured to
the shield buses/plates with the fixing accessories provided to ensure proper EMC.
PE busbar The PE busbars between the cabinet units or transport units
must be connected.
A
connection is then established to ground the complete sys‐
tem.
(Chapter Installation / connect cabinet units / Connect PE
busbars").
Checklists and forms
C.2 Electrical installation: Checklist
Applications for Cabinet Modules, liquid cooled
146 Operating Instructions, 04/2015, A5E35974555A
