Modbus RTU RS-485
20
SFIDK.PS.023.D2.02
Modbus Modbus No. of Data Read/
register address bytes type
Description
write
4:02214 2213 4 Float Frequency 1 Timeconstants R/W
4:02216 2215 2 Byte
Limit Digital selection:
0 = Off (read only)
1 = Massflow
2 = Fraction A
3 = Fraction B R/W
4 = Volumeflow
5 = Sensor temp.
6 = Density
7 = % fraction A
4:02217 2216 2 Byte
Limit Digital mode:
0 = 1 setpoint R/W
1 = 2 setpoints
4:02218 2217 4 Float Limit Digital Setpoint min. (1/100%) R/W
4:02220 2219 4 Float Limit Digital Setpoint max. (1/100%) R/W
4:02222 2221 4 Float Limit Digital Hysteresis (1/100%) R/W
4:02224 2223 2 Byte
Relay Output 1 function:
0 = Off
3 = Error Level R/W
4 = Error Number
5 = Direction/Limit
4:02225 2224 2 Byte
Limit Relay selection:
0 = Off
1 = Massflow
2 = Fraction A
3 = Fraction B R/W
4 = Volumeflow
5 = Sensor temp.
6 = Density
7 = % fraction A
4:02226 2225 2 Byte
Limit Relay mode:
0 = 1 setpoint R/W
1 = 2 setpoints
4:02227 2226 4 Float Limit Relay Setpoint min. (1/100%) R/W
4:02229 2228 4 Float Limit Relay Setpoint max. (1/100%) R/W
4:02231 2230 4 Float Limit Relay Hysteresis (1/100%) R/W
4:02233 2232 2 Byte Error number (0-255) R/W
4:02234 2233 2 Byte
Batch selection:
0 = Off (read only)
1 = Massflow
2 = Fraction A
R/W
3 = Fraction B
4 = Volumeflow
4:02235 2234 4 Float Batch Quantity (kg or m
3
) R/W
4:02237 2236 4 Float Batch Compensation R/W
4:02239 2238 4 Float Batch Lead constant R/W
4:02241 2240 2 Byte
Batch Time error on/off:
0 = Off R/W
1 = On
4:02242 2241 4 Float Max. Batch time (s) R/W
4:02244 2243 2 Byte
Batch overrun on/off:
0 = Off R/W
1 = On
4:02245 2244 4 Float Batch overrun error (kg or m
3
) R/W
4:02247 2246 2 Byte Batch counter up/down
0 = Down R/W
1 = Up
4:02250 2249 4 Dword Batch cycle counter R
4:02291 2290 4 Float Mass or Volume
per pulse (kg or m
3
)
R/W
4:02296 2295 2 Byte
Quadratur:
0 = Off R/W
1 = On
6. Modbus holding registers
6.6 Output
(continued)
MASS 6000
