Siemens SITRANS F M MAGFLO series - Modbus Coils; 7.2 Auto zero adjust; 7.4 Batch

Modbus RTU RS-485
26
SFIDK.PS.023.D2.02
In the following the coils for the USM II Modbus RTU module are described.
7. Modbus coils
7. Modbus coils
Figure:
Memory map for coils
Modbus Modbus Data Read/
register address type
Description
write
0:00001 0 Coil Restart Modbus communication:
Write: 0 = No effect
1 = Restart
R/W
Read: always 0
Modbus Modbus Data Read/
register address type
Description
write
0:00009 8 Coil Start auto zero adjust:
Write: 0 = No effect
1 = StartRead:
R/W
0 = Idle1 = Busy
Modbus Modbus Data Read/
register address type
Description
write
0:00010 9 Coil Reset totalizer 1:
Write: 0 = No effect
1 = ResetRead:
R/W
always 0
0:00011 10 Coil Hold totalizer 1:
Write: 0 = Run
1 = HoldRead:
R/W
0 = Not held1 = Held
0:00012 11 Coil Reset totalizer 2:
Write: 0 = No effect
1 = ResetRead:
R/W
always 0
0:00013 12 Coil Hold totalizer 2:
Write: 0 = Run
1 = HoldRead:
R/W
0 = Not held1 = Held
Modbus Modbus Data Read/
register address type
Description
write
0:00014 13 Coil Start Batch:
Write: 0 = Stop Batch
1 = Start BatchRead:
R/W
0 = Stopped1 = Not stopped
0:00015 14 Coil Pause Batch:
Write: 0 = Resume Batch
1 = Pause BatchRead:
R/W
0 = Not paused1 = Paused
7.1 Communication
settings
7.2 Auto zero adjust
7.3 Totalizer
7.4 Batch
Control/status
0
20
655535
