Siemens SITRANS F M MAGFLO series - APPENDIX G - Units and Point Positions

Modbus RTU RS-485
34
SFIDK.PS.023.D2.02
APPENDIX G
APPENDIX G - Units and Point positions
Volumeflow units
Massflow unit
01234567891011 1213 14 15
m3/s ml/s L/s hl/s kl/s Ml/s m3/s m3/s ft3/s in3/s USGPS USMGPS UKGPS UKMGPS USkGPS UKkGPS
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
m3/min ml/min L/min hl/min kl/min Ml/min m3/min m3/min ft3/min in3/min USGPM USMGPM UKGPM UKMGPM USkGPM UKkGPM
32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47
m3/h ml/h L/h hl/h kl/h Ml/h m3/h m3/h ft3/h in3/h USGPH USMGPH UKGPH UKMGPH USkGPH UKkGPH
48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63
m3/d ml/d L/d hl/d kl/d Ml/d m3/d m3/d ft3/d in3/d USGPD USMGPD UKGPD UKMGPD USkGPD UKkGPD
64 - 255: Reserved
01234567891011121314 15
kg/s ton/s lb/s mg/s g/s kg/s kg/s kg/s kg/s kg/s kg/s kg/s kg/s kg/s kg/s kg/s
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
kg/min ton/min lb/min mg/min g/min kg/min kg/min kg/min kg/min kg/min kg/min kg/min kg/min kg/min kg/min kg/min
32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47
kg/h ton/h lb/h mg/h g/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h
48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63
kg/d ton/d lb/d mg/d g/d kg/d kg/d kg/d kg/d kg/d kg/d kg/d kg/d kg/d kg/d kg/d
64 - 255: Reserved
Density unit
Totalizer unit volume
01234567891011 1213 14 15
M3 Ml l hl kl Ml m3 m3 ft3 in3 USG USMG UKG UKMG USkG UKkG
16 - 254: Reserved
Totalizer unit massflow
01234
kg ton lb Mg G
5 - 255: Reserved
0123 45 6 789101112131415
kg/m3 ton/m3 Lb/m3 mg/m3 g/m3 kg/ m3 kg/ m3 kg/ m3 kg/ m3 kg/ m3 kg/ m3 kg/ m3 kg/ m3 kg/ m3 kg/ m3 kg/ m3
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
kg/ft3 ton/ft3 lb/ft3 mg/ft3 g/ft3 kg/ft3 kg/ft3 kg/ft3 kg/ ft3 kg/ ft3 kg/ ft3 kg/ ft3 kg/ ft3 kg/ ft3 kg/ ft3 kg/ ft3
32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47
kg/in3 ton/in3 lb/ in3 mg/ in3 g/ in3 kg/ in3 kg/ in3 kg/ in3 kg/ in3 kg/ in3 kg/ in3 kg/ in3 kg/ in3 kg/ in3 kg/ in3 kg/ in3
48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63
kg/cm3 ton/cm3 lb/cm3 mg/cm3 g/cm3 kg/cm3 kg/cm3 kg/cm3 kg/cm3 kg/cm3 kg/cm3 kg/cm3 kg/cm3 kg/cm3 kg/cm3 kg/cm3
64 - 255: Reserved
Point position
0 = no digits after the decimal point
1 = one digit after the decimal point
2 = two digits after the decimal point
3 = three digits after the decimal point
4 = four digits after the decimal point
5 = five digits after the decimal point
6 = six digits after the decimal point
7 - 255: Reserved
