Siemens SITRANS P DS III Service Manual

Introduction
1.4 Checking the consignment
SITRANS P DS III
8 Service Manual, 06/2014, A5E34219855-01
1.4
Checking the consignment
1. Check the packaging and the spare parts for visible damage caused by inappropriate
handling during shipping.
2. Report any claims for damages immediately to the shipping company.
3. Retain the damaged parts for clarification.
4. Check the scope of delivery by comparing your order with the shipping documents for
correctness and completeness.
WARNING
Using damaged or incomplete spare parts
Danger of explosion in hazardous areas.
• Do not use damaged or incomplete spare parts.
1.5
Purpose
Overview
Depending on the version, a transmitter measures corrosive, non-corrosive and hazardous
gases, vapors and liquids.
You can use the transmitter for the following types of measurement:
● Gauge pressure
● Absolute pressure
● Differential pressure
With appropriate parameter settings and the necessary add-on parts (e.g. flow orifices and
remote seals), the pressure transmitter can also be used for the following measurements:
● Level
● Volume
● Mass
● Volume of flow
● Mass flow rate
The output signal is always a load-independent direct current between 4 and 20 mA.
You can install the "intrinsically-safe" or "explosion-proof" version of the transmitter in
hazardous areas. The devices have an EC type examination certificate and comply with the
appropriate harmonized European CENELEC directives.
Transmitters with remote seals of different shapes can be delivered for special applications.
For example, measuring high-viscosity substances is a special application.

Siemens SITRANS P DS III Specifications

General

Type	Pressure Transmitter
Communication	HART, PROFIBUS PA, FOUNDATION Fieldbus
Housing material	Aluminum or Stainless Steel
Measured variable	Pressure
Output signal	4...20 mA HART, PROFIBUS PA, Foundation Fieldbus
Ambient temperature range	-40 to +85 °C
Power supply	10.5...45 V DC
Protection class	IP66, IP67
Process connection	Various
