117
Thorax
Embolism 2
nd
reconstr.
kV 130
Effective mAs 70
Slice collimation 1.0 mm
Slice width 3.0 mm 1.25 mm
Feed/Rotation 9.0 mm
Rotation time 0.6 sec.
Kernel B41s B41s
Increment 3.0 mm 0.8 mm
Image order cr-ca
CTDI
Vol
9.2 mGy
* CARE Bolus may be used to optimize the bolus timing.
Set the ROI for monitoring scan in the truncus
pulmonalis with triggering threshold of 120 HU,
or use manual triggering.
Contrast medium IV injection
Start delay 12 – 15 sec.*
Flow rate 4 ml/sec.
Total amount 80 – 100 ml
MIPthin: Embolism coronal
Image thickness 3
Distance between images 3
Number of images 35
For the 2
nd
reconstruction the Autoload into MIPthin
Range on the 3D Card is activated. The images will be
automatically loaded into 3D, MIPthin, and a coronal
MIPthin Range will pop up.
Please notice, if you are not satisfied with the Range
preset adapt the parameters to your needs and link them
to the series.
