38
Children
Sinus
Indications:
Spiral mode for routine spiral studies of the sinuses
and for the paranasal sinuses when Multi Planar
Reformation (MPR) are intended, e. g. sinusitis, pneu-
matization, polyposis, malformations, tumors etc.
A range of 4 cm will be covered in 8.7 sec.
Sinus 2
nd
reconstr.
kV 110
Effective mAs *
Slice collimation 1.0 mm
Slice width 3.0 mm 1.25 mm
Feed/Rotation 6.0 mm
Rotation time 1.0 sec.
Kernel C30s C60s
Increment 3.0 mm 0.8 mm
Image order ca-cr
* The mAs should be adjusted to the age of the child.
