125
Thorax
ThoraxRoutine
kV 130
Effective mAs 70
Slice collimation 2.0 mm
Slice width 5.0 mm
Feed/Rotation 16.0 mm
Rotation time 0.6 sec.
Kernel B41s
Increment 5.0 mm
Image order cr-ca
CTDI
Vol
8.0 mGy
You could repeat the same protocol simply by clicking
the chronicle with the right mouse button for “repeat“.
E. g. when both non-contrast and contrast studies are
required.
For lung cancer staging, this protocol can be combined
with protocol “Neck Routine”.
Contrast medium IV injection
Start delay 25 – 30 sec.
Flow rate 2.5 ml/sec.
Total amount 80 ml
