169
Pelvis
Hip 2
nd
reconstr.
kV 130
Effective mAs 95
Slice collimation 1.0 mm
Slice width 5.0 mm 1.25 mm
Feed/Rotation 9.0 mm
Rotation time 1.0 sec.
Kernel B41s B70s
Increment 5.0 mm 0.8 mm
Image order cr-ca
CTDI
Vol
12.5 mGy
In case of 3D study only, mAs can be reduced up to
50%, images should be reconstructed with at least 50%
overlapping and kernel B10s.
If only one side is examined, it is advisable to enter the
side in the comment line on the routine card.
MPRthick: Hip coronal
Image thickness 3
Distance between images 3
Number of images 20
For the 2
nd
reconstruction the Autoload into the MPR
Range on the 3D Card is activated. The images will
be automatically loaded into 3D, MPR, and a coronal
MPRthick Range will pop up.
Please notice, if you are not satisfied with the Range
preset adapt the parameters to your needs and link them
to the series.
