179
Spine
Spine 2
nd
reconstr.
kV 130
Effective mAs 190
Slice collimation 2.0 mm
Slice width 2.5 mm 2.5 mm
Feed/Rotation 8.0 mm
Rotation time 1.0 sec.
Kernel B31s B60s
Increment 2.5 mm 1.5 mm
Image order cr-ca
CTDI
Vol
21.6 mGy
MPRthick: Spine coronal
Image thickness 3
Distance between images 3
Number of images 30
For the 2
nd
reconstruction the Autoload into the MPR
Range on the 3D Card is activated. The images will
be automatically loaded into 3D, MPR, and a coronal
MPRthick Range will pop up.
Please notice, if you are not satisfied with the Range
preset adapt the parameters to your needs and link them
to the series.
