181
Spine
C-Spine 2
nd
reconstr.
kV 130
Effective mAs 150
Slice collimation 1.0 mm
Slice width 3.0 mm 1.25 mm
Feed/Rotation 6.0 mm
Rotation time 1.0 sec.
Kernel B31s B60s
Increment 3.0 mm 0.8 mm
Image order cr-ca
CTDI
Vol
19.8 mGy
MPRthick: C-Spine sagittal
Image thickness 3
Distance between images 3
Number of images 20
For the 2
nd
reconstruction the Autoload into the MPR
Range on the 3D Card is activated. The images will be
automatically loaded into 3D, MPR, and a sagittal
MPRthick Range will pop up.
Please notice, if you are not satisfied with the Range
preset adapt the parameters to your needs and link them
to the series.
